Executive Summary

The relentless expansion of data-intensive applications, particularly in artificial intelligence (AI), high-performance computing (HPC), and hyperscale data centers, has pushed traditional electrical interconnects to their fundamental physical limits. The impending “power wall,” where the energy consumed to move data threatens to eclipse the energy used for computation, signals the end of an era dominated by copper. This report provides an exhaustive analysis of the paradigm shift toward optical interconnects, with a specific focus on silicon photonics (SiPh) as the pivotal technology enabling this transition. The move to optical communication is no longer a question of ‘if’ but ‘when and how,’ driven by the unsustainable power consumption, limited bandwidth density, and signal integrity challenges of copper-based systems.

Silicon photonics has emerged as the leading platform to resolve this interconnect crisis. By uniquely leveraging the mature, high-volume manufacturing ecosystem of the complementary metal-oxide-semiconductor (CMOS) industry, SiPh facilitates the creation of complex Photonic Integrated Circuits (PICs) at an unprecedented scale and cost-effectiveness. This technology integrates essential optical components—such as modulators, photodetectors, and waveguides—onto a single silicon chip, creating a pathway for light to replace electrons in data transmission.

This report examines the application of silicon photonics across two critical domains. First, within the data center, it traces the evolution from pluggable optical transceivers and Active Optical Cables (AOCs) to the disruptive architecture of Co-Packaged Optics (CPO). CPO, which integrates optical engines directly with switch and processor ASICs, promises order-of-magnitude improvements in power efficiency and bandwidth density, fundamentally reshaping network topologies. Second, at the chip-package level, the report details the rise of in-package optical I/O (OIO) and photonic chiplets. This technology is poised to shatter the “I/O wall” that currently throttles processor performance, enabling novel, disaggregated system architectures where resources like memory and compute can be pooled across a data center with the latency and bandwidth of on-package connections.

The analysis extends to a strategic overview of the global silicon photonics ecosystem, profiling the foundational foundries (GlobalFoundries, TSMC), vertically integrated giants (Intel, Cisco), key system drivers (NVIDIA, Broadcom), and disruptive startups (Ayar Labs, Lightmatter). It also provides a sober assessment of the significant manufacturing, packaging, and thermal management challenges that must be overcome for the technology to achieve ubiquity.

Ultimately, this report concludes that silicon photonics is no longer a speculative research topic but a foundational, commercially viable technology central to the future of the entire computing industry. Its adoption is an economic and physical inevitability. Stakeholders—from investors and engineers to policymakers—must develop strategies that account for a future where the speed, scale, and efficiency of data are defined not by electrons, but by light.

Section 1: The End of the Copper Era: The Imperative for Optical Interconnects



The foundation of modern digital infrastructure has been built upon the reliable, cost-effective conductivity of copper. However, the exponential growth in data generation and processing is exposing the fundamental physical limitations of using electrons to transmit information over metallic wires. This section establishes the physics-based and economic drivers compelling the industry to move beyond copper, framing the issue not merely as a need for more speed, but as a systemic crisis in power, thermal management, and architectural scalability.



1.1 The Physics of Diminishing Returns: Analyzing the Fundamental Limits of Electrical Interconnects



As data rates escalate and interconnect lengths increase, copper-based systems encounter a cascade of physical barriers that lead to diminishing returns in performance and efficiency.

  • Signal Attenuation and Reach: An electrical signal propagating through a copper wire loses strength, or attenuates, due to the wire’s inherent resistance, which dissipates signal energy as heat.1 This insertion loss is a function of both distance and frequency; the higher the data rate (frequency) and the longer the cable, the greater the signal degradation.1 This physical constraint severely limits the effective reach of high-speed copper links. For example, standard Category 6 or 7 Ethernet cables are capped at a 100-meter reach for a 10 Gbps data rate.1 As speeds increase to 200 Gbps, the reach of copper shrinks so dramatically that it can no longer reliably span the full length of a single server rack, creating a significant architectural constraint in data centers.2
  • Electromagnetic Interference (EMI) and Crosstalk: Copper’s nature as an excellent electrical conductor also makes it an effective antenna. This renders copper cables highly susceptible to picking up electromagnetic noise from nearby power lines and electronic devices (EMI) and to signal bleed from adjacent cables (crosstalk).1 This interference corrupts the signal, increasing the bit error rate. To mitigate this, complex shielding is required, which adds significant bulk, weight, and rigidity to the cables, complicating installation and impeding airflow in dense environments. Alternatively, power-hungry digital signal processors (DSPs) must be employed to clean and reconstruct the degraded signal, adding both latency and power consumption to the link.6
  • The Power and Thermal Bottleneck: The resistance that causes signal attenuation also dictates that pushing more data through copper requires a disproportionate increase in power, which is almost entirely converted into waste heat.7 This has created a critical “power wall” in modern computing systems. In many-core processors, interconnects are already a dominant power consumer, with projections indicating they could account for up to 80% of a microprocessor’s total power budget.10 This immense power draw translates directly into a thermal crisis. The generated heat limits the density of components, requires expensive and complex cooling infrastructure, and ultimately throttles the performance of the entire system to avoid overheating.10
  • Bandwidth Density Constraints: The physical volume of shielded, high-speed copper cables imposes a hard limit on the number of connections that can be physically accommodated in a given area, such as the front panel of a network switch or the edge of a processor package. This creates a bandwidth density bottleneck, where the physical space for I/O, not the capability of the silicon, becomes the limiting factor for system throughput.1



1.2 The Paradigm Shift to Photonics: Principles of Optical Data Transmission



Optical interconnects circumvent the fundamental limitations of copper by using photons (particles of light) instead of electrons to carry information. Data is transmitted as modulated light pulses through a dielectric medium, typically a glass or plastic fiber, which offers a profoundly different set of physical properties.4

  • Fundamental Advantages:
  • Vastly Higher Bandwidth: The frequency of light is orders of magnitude higher than that of electrical signals used in copper wires, providing a vastly larger information-carrying capacity. While copper struggles to reach 100 Gbps over a few meters, a single optical fiber can carry multiple channels at 100 Gbps or more, with a theoretical potential for terabits per second using techniques like wavelength-division multiplexing (WDM).4
  • Extended Reach: Light propagates through high-purity optical fiber with extremely low attenuation, allowing signals to travel for several kilometers without the need for amplification or regeneration. This is a stark contrast to high-speed copper, whose reach is measured in meters.4
  • EMI Immunity: Because photons are electrically neutral particles and the glass fiber is a dielectric, optical signals are completely immune to electromagnetic interference, radio frequency interference (RFI), and crosstalk. This ensures exceptionally high signal integrity even in the most electromagnetically noisy environments, such as a dense data center rack.4
  • Lower Power Consumption: For an equivalent data rate and distance, transmitting data with photons requires significantly less energy than with electrons. This is because minimal energy is lost as heat during transmission through the low-loss fiber medium. In dense computing environments, optical interconnects can consume up to 70% less power than their copper counterparts, directly addressing the power and thermal bottlenecks.4
  • Superior Physical Properties: Fiber optic cables are substantially thinner, lighter, and more flexible than high-speed copper cables. This simplifies cable management, improves airflow for cooling, and allows for much denser interconnect configurations.1

The limitations of copper are no longer a simple communication issue but have evolved into a primary constraint on the architectural evolution of computing systems. The power, thermal, and density limits imposed by electrical interconnects directly throttle the performance scaling of the massive, parallel systems required for AI and HPC. To build larger, more powerful AI training clusters, for instance, thousands of GPUs must be tightly coupled to maximize parallel processing capabilities.16 Copper’s high power consumption and limited reach at high speeds force system architects into undesirable compromises; they cannot place components as densely or as far apart as architecturally optimal without incurring a severe power or latency penalty. This creates systemic bottlenecks where processors are starved for data, and overall system performance is limited by the interconnect, not by the computational power of the silicon itself.7 Therefore, the transition to optical interconnects is not merely an incremental upgrade for speed; it is a necessary, enabling step to unlock new system architectures that are fundamentally impossible to build with copper.

Metric Advanced Copper (DAC) Silicon Photonics (SiPh) Indium Phosphide (InP) Polymer Photonics
Bandwidth Density Low to Medium Very High High Medium
Typical Reach < 10 meters < 2 kilometers (Data Center) > 80 kilometers (Long-Haul) < 100 meters
Power Efficiency (pJ/bit) > 10 pJ/bit (at reach) < 5 pJ/bit (OIO) to ~8 pJ/bit (Transceiver) Variable (Optimized for performance) Low (for short reach)
Latency Very Low (for < 1m) Low High (due to DSPs) Low
EMI/Crosstalk Immunity Low (Susceptible) Very High (Immune) Very High (Immune) Very High (Immune)
Manufacturing Scalability & Cost High (Mature) Very High (CMOS-based) Low (Specialized fabs, small wafers) High (Potentially low-cost processing)
Primary Application Domain In-rack, short-reach (< 3m) Data Center, Chip-to-Chip, CPO, OIO Long-Haul/Metro Coherent Board-level, flexible interconnects

Table 1: A comparative analysis of key performance metrics across different interconnect technologies. Data is synthesized from multiple sources to provide a strategic overview of the trade-offs inherent in each platform.1

Section 2: Silicon Photonics: A Platform for Mass-Market Optoelectronics



While the theoretical benefits of optical communication have been understood for decades, the primary barrier to its widespread adoption within computing has been cost and manufacturability. Traditional optical components, often assembled manually from discrete parts using exotic materials, were too expensive for high-volume applications like data centers. Silicon photonics has shattered this barrier by providing a platform to fabricate complex optical systems using the same mass-production techniques that made the microchip ubiquitous. This section details why silicon photonics is the key enabling technology for the optical interconnect revolution.



2.1 Leveraging the CMOS Revolution: The Strategic Advantage of Silicon-on-Insulator (SOI) Platforms



The core strategic advantage of silicon photonics is its profound synergy with the existing Complementary Metal-Oxide-Semiconductor (CMOS) manufacturing ecosystem, the most mature and highest-volume industrial process in human history.23 This compatibility allows for the fabrication of Photonic Integrated Circuits (PICs) in the same foundries, using much of the same equipment, as conventional electronic chips. This immediately unlocks unprecedented economies of scale, precision, and the potential for monolithic integration of electronics and photonics on a single chip, driving down costs and enabling mass-market deployment.23

The foundational material for this platform is the Silicon-on-Insulator (SOI) wafer. An SOI wafer consists of a thin, crystalline top layer of silicon (typically a few hundred nanometers thick) separated from the bulk silicon substrate by an insulating layer of silicon dioxide (SiO2​), often referred to as the buried oxide (BOX).24 This structure is ideal for photonics for two key reasons:

  1. Optical Properties: Silicon is transparent to the infrared wavelengths of light used in telecommunications and data communications (typically in the 1.3 µm to 1.6 µm range).26
  2. Light Confinement: Silicon possesses a very high refractive index (n≈3.45) compared to that of silicon dioxide (n≈1.45). This large index contrast allows for the principle of total internal reflection to tightly confine light within waveguides patterned into the top silicon layer. This strong confinement enables the creation of extremely compact optical components, such as waveguides with sub-micron cross-sections and sharp bends with radii of just a few micrometers, facilitating the dense integration of complex optical circuitry on a small chip area.24



2.2 The Integrated Photonic Circuit (PIC): A Component-Level Deep Dive



A PIC is the optical analogue of an electronic integrated circuit, comprising various active and passive components that manipulate light to perform specific functions.



2.2.1 Waveguides: The “Wires” of Light



Waveguides are the most fundamental component of a PIC, serving as the passive conduits that guide and route light across the chip, analogous to copper traces in an electronic circuit.29 They are formed by etching patterns into the top silicon layer of the SOI wafer. The performance of a waveguide—specifically its propagation loss—is critically dependent on the precision of the CMOS fabrication process. Sidewall roughness caused by the etching process can scatter light out of the waveguide, leading to signal loss. Therefore, advanced lithography and etching techniques are essential for creating smooth-walled waveguides that can transport light efficiently over centimeters with minimal loss.24 The tight light confinement in SOI waveguides allows for very small bend radii, a key feature that enables the high-density integration of components on a PIC.24



2.2.2 Modulators: Encoding Data at Terabit Speeds



Optical modulators are active devices that encode electrical data onto a beam of light. They are the critical interface between the electronic and photonic domains.29 In silicon, modulation is typically achieved through the

plasma dispersion effect. By applying a voltage across a p-n junction embedded in or near a waveguide, free charge carriers (electrons and holes) can be injected into or depleted from the silicon. This change in the free carrier concentration alters the refractive index and optical absorption of the silicon, thereby modulating the phase or amplitude of the light passing through it.19 Several architectures are used to translate this physical effect into a high-speed modulator:

  • Mach-Zehnder Interferometer (MZI): This is a widely used and robust modulator design. An MZI splits an incoming light beam into two separate waveguides (the “arms” of the interferometer). A phase shifter, based on the plasma dispersion effect, is placed in one or both arms. By applying a voltage, the refractive index is changed, altering the speed of light in that arm and thus shifting its phase relative to the other. When the two beams are recombined, they interfere either constructively (creating a bright output, a ‘1’ bit) or destructively (creating a dark output, a ‘0’ bit), effectively converting the electrical voltage signal into an intensity-modulated optical signal.32
  • Microring Resonator (MRM): An MRM consists of a tiny, ring-shaped waveguide placed very close to a straight “bus” waveguide. Light from the bus waveguide can couple into the ring and circulate. This only occurs efficiently at specific resonant wavelengths, which are extremely sensitive to the ring’s refractive index. By using the plasma dispersion effect to slightly alter the ring’s refractive index, the resonant wavelength can be shifted. This allows the MRM to act as a switch or modulator: when the incoming light’s wavelength is on-resonance, it is coupled into the ring and absorbed or dropped to another port; when it is off-resonance, it passes by unaffected. MRMs are prized for their incredibly small footprint and very low power consumption, but they are highly sensitive to temperature variations and typically have a narrower optical bandwidth than MZIs.23



2.2.3 Photodetectors: Converting Light Back to Electrons



At the receiving end of an optical link, a photodetector performs the optical-to-electrical conversion, absorbing photons and generating a corresponding electrical current.29 A challenge here is that pure silicon is a poor absorber of light at the standard telecommunication wavelengths. To overcome this, germanium (Ge) is integrated into the silicon photonic platform. Germanium has a direct bandgap and strong absorption in the infrared spectrum. Using selective epitaxial growth processes, which are compatible with CMOS manufacturing, high-purity germanium can be grown directly on top of the silicon waveguides. This creates high-speed, efficient photodetectors that can be seamlessly integrated into the PIC.26



2.3 The Light Source Dilemma: The Challenge and Solutions for Integrating Lasers



The most significant fundamental challenge for silicon photonics is that silicon, due to its indirect bandgap electronic structure, is an extremely inefficient light emitter. Electrons and holes in silicon cannot recombine to produce a photon efficiently, making it impossible to create a practical laser directly from silicon.8 This “light source problem” has been the holy grail of silicon photonics research for decades. The prevailing solution is not to force silicon to lase, but to integrate materials that are naturally excellent light emitters—namely, direct-bandgap III-V compound semiconductors like Indium Phosphide (InP) and Gallium Arsenide (GaAs)—onto the silicon platform.24 This is achieved through two primary strategies:

  • Hybrid and Heterogeneous Integration:
  • Hybrid Integration: This approach, often using flip-chip bonding, involves fabricating the III-V laser diode on its native substrate (e.g., InP) and the silicon PIC on an SOI wafer separately. The fully formed laser die is then precisely aligned and bonded onto the PIC. This allows for the separate optimization of both the laser and the photonic circuit, but the high-precision alignment required for efficient light coupling between the two chips is a complex and costly packaging step.12
  • Heterogeneous Integration: This more advanced technique involves bonding a thin layer of unprocessed III-V material directly onto the SOI wafer at the wafer scale. The III-V material can then be processed alongside the silicon components using CMOS-compatible techniques to form lasers that are monolithically integrated with the silicon waveguides. This method offers the potential for much tighter integration and lower-cost, wafer-scale manufacturing.36
  • External Laser Source (ELS): For many applications, particularly Co-Packaged Optics, the laser source is kept off-chip entirely. A separate, high-power laser module generates the light, which is then delivered to the PIC via optical fibers. This approach has the significant advantage of thermally isolating the heat-generating laser from the temperature-sensitive PIC and the main electronic ASIC, simplifying thermal management. However, it requires robust and low-loss fiber-to-chip coupling.40

The true innovation of silicon photonics lies not in the idea that silicon is the best optical material for every function, but rather that it is a sufficiently good and supremely manufacturable platform onto which superior materials can be strategically integrated. A pure Indium Phosphide platform, for example, offers inherently better performance for active components like lasers and modulators due to its superior physical properties.19 However, InP fabrication relies on smaller, more expensive wafers and lacks the vast, mature, and cost-optimized manufacturing ecosystem of silicon CMOS.42 Silicon photonics strategically accepts silicon’s optical deficiencies (no light emission, less efficient modulation) in order to leverage its unparalleled manufacturing advantage. It then solves these material shortcomings through a “best-of-breed” heterogeneous approach, integrating small amounts of III-V materials or Germanium only where they are absolutely necessary. This creates a system that is economically viable for mass production—a classic engineering trade-off that prioritizes scalability and cost over the raw performance of individual components, thereby enabling the technology to address mass markets like data centers.

Section 3: Revolutionizing Data Center Architectures with Light



The data center is the primary battleground where the limitations of copper are most acute and the benefits of silicon photonics are most profound. The relentless growth in data traffic, driven by cloud computing and AI, is forcing a fundamental rethink of data center network architecture. This section explores the tangible application of silicon photonics within the data center, tracing the evolution from discrete pluggable modules to deeply integrated solutions that are poised to redefine how data centers are built.



3.1 From Pluggable Transceivers to Active Optical Cables (AOCs): The Incumbent Solutions



The initial adoption of optics in the data center occurred at the longer-reach links between racks and rows, using standardized, hot-pluggable modules.

  • Optical Transceivers: These are compact modules, conforming to standards like QSFP (Quad Small Form-factor Pluggable) and OSFP (Octal Small Form-factor Pluggable), that plug into the front panel of network switches and servers. They perform the essential optical-to-electrical (O/E) and electrical-to-optical (E/O) conversions. Silicon photonics has become a dominant technology for manufacturing high-speed transceivers (e.g., 100G, 400G, 800G, and emerging 1.6T).43 By integrating multiple components—such as modulators, drivers, photodetectors, and wavelength multiplexers/demultiplexers (MUX/DEMUX)—onto a single PIC, SiPh-based transceivers can be made smaller, more power-efficient, and at a lower cost compared to traditional transceivers assembled from dozens of discrete optical parts.25
  • Active Optical Cables (AOCs): An AOC is a simplified interconnect solution consisting of a fiber optic cable with the transceiver optics permanently attached, or bonded, to each end.47 This creates a self-contained, plug-and-play cable assembly. The key advantage of an AOC is its enhanced reliability and ease of use; by eliminating the physical fiber optic connector interface, it removes a major point of failure and contamination (e.g., dust) that plagues traditional links.48 High-performance AOCs leverage silicon photonics to achieve significantly longer reach (up to several kilometers) and superior data integrity (lower bit error rates) compared to shorter-reach AOCs that use vertical-cavity surface-emitting lasers (VCSELs) and multimode fiber.48



3.2 Co-Packaged Optics (CPO): The Architectural Endgame for Network Switches



While pluggable modules brought optics to the data center, they still rely on a long, power-hungry electrical connection from the main switch ASIC to the front panel of the chassis. Co-Packaged Optics (CPO) is a disruptive architecture designed to eliminate this final electrical bottleneck.

  • The CPO Concept: CPO moves the optical I/O function from the pluggable front-panel module directly onto the same package substrate as the primary ASIC, such as a high-radix network switch chip or a processor.6 This is achieved by placing small, highly integrated silicon photonic “optical engines” or chiplets in close proximity to the switch die within a single multi-chip module.
  • Analysis of Gains: The architectural benefits of this integration are profound:
  • Drastic Power Reduction: The primary driver for CPO is a dramatic reduction in I/O power consumption, with major vendors reporting savings of over 3.5 times compared to pluggable solutions.6 This is achieved by eliminating the long (often 14-16 inches) and lossy electrical traces on the printed circuit board that connect the switch ASIC to the front-panel cages. These high-speed electrical links (SerDes) are a major source of power consumption, and shortening them from inches to millimeters within the package yields massive energy savings.6
  • Unprecedented Bandwidth Density: By removing the physical constraints of front-panel pluggable modules, CPO allows for a much higher density of optical I/O directly from the switch package. This bandwidth density is measured in terabits per second per millimeter (Tbps/mm) of the package edge, enabling switch chips with far greater total bandwidth than is possible with a pluggable architecture.6
  • Reduced Latency: Shortening the electrical path and, in many cases, eliminating the need for power-hungry retiming DSPs that are required in pluggable modules, significantly reduces the latency of the I/O path. This is a critical advantage for latency-sensitive HPC and AI training workloads.40
  • Case Studies and Industry Adoption: The move to CPO is being aggressively pursued by key industry players:
  • NVIDIA: Is integrating silicon photonics directly with its Spectrum switch ICs, leveraging CPO to achieve 3.5x lower power consumption and claiming a 1.3x faster deployment time for CPO-based systems.40
  • Broadcom: Is already shipping production CPO systems based on its highly integrated silicon photonics engines. They are co-packaging these engines with their Tomahawk switch ASICs and custom processors (XPUs), targeting the demanding needs of AI networks and claiming a 40% lower optics cost per bit.6
  • Intel: As a vertically integrated leader in silicon photonics, Intel is heavily invested in developing CPO technology to be integrated with its future switch and processor products.41



3.3 Reimagining Topologies: How CPO Frees Data Centers from Electrical Constraints



The architectural implications of CPO extend beyond a single switch. By breaking free from the I/O density limitations of the front panel, CPO enables the design of switch ASICs with a much higher radix (the number of ports per chip). This allows network architects to build flatter, more efficient network topologies (such as Dragonfly+ or flattened butterfly networks) that reduce the number of network tiers, minimize the number of hops a packet must take, and lower overall end-to-end latency across the data center.54 This fundamental re-partitioning of network hardware is a direct result of the capabilities unlocked by silicon photonics integration.54

The move to CPO is a catalyst for a necessary convergence of design disciplines. In the traditional pluggable model, switch ASIC designers and optics engineers could work in relative isolation, connected by a standardized electrical interface. A CPO system, however, is a deeply integrated, multi-physics entity. The immense heat generated by the switch ASIC (often hundreds of watts) is now in direct thermal contact with the highly temperature-sensitive photonic components, creating a complex thermal management challenge.52 The mechanical routing of hundreds of optical fibers to and from the package becomes a formidable packaging problem.8 Power delivery for the optical engines must be integrated into the package substrate. Consequently, designing a successful CPO product requires a holistic, system-level co-design methodology. Electrical, optical, thermal, and mechanical properties must be co-simulated and co-optimized concurrently, representing a significant increase in design complexity but also the only path to realizing the profound system-level benefits of this new architecture.41

Section 4: The Final Frontier: Optical Communication On-Package and On-Chip



While CPO revolutionizes communication between servers and racks, the next frontier for silicon photonics is to solve the interconnect bottlenecks inside the computing package itself. As the performance of processors continues to scale, the ability to feed them with data and to connect them to memory and other processors is becoming the primary limiting factor. This section examines how silicon photonics is poised to enable a new era of heterogeneous integration and system design at the chip level.



4.1 Breaking the I/O Wall: Optical I/O for Processors



Modern processors—including CPUs, GPUs, and specialized AI accelerators—are facing an “I/O wall.” The number of electrical pins that can be placed on the perimeter of a chip package is physically limited, and driving high-speed electrical signals off-package consumes a significant portion of the chip’s power budget. This creates a bottleneck that limits the amount of data that can be moved in and out of the processor, effectively starving the powerful compute cores and creating a “memory wall” where the processor waits idly for data.13

In-Package Optical I/O (OIO) is the solution to this problem. This approach involves integrating small, specialized silicon photonics chiplets directly into the same advanced package as the main processor die.21 These OIO chiplets function as extremely high-bandwidth, power-efficient “on-ramps” and “off-ramps” for data. They take parallel electrical signals from the processor die, convert them into optical signals, and transmit them off-package via a dense array of optical fibers. This provides a massive increase in off-package bandwidth at a fraction of the power of electrical I/O, effectively demolishing the I/O wall.21



4.2 Chiplets and Heterogeneous Integration: Silicon Photonics as the High-Bandwidth Fabric



The semiconductor industry is rapidly moving away from designing large, monolithic Systems-on-Chip (SoCs) towards a chiplet-based design paradigm. This approach involves breaking down a complex SoC into smaller, specialized dies or “chiplets” (e.g., a CPU core chiplet, a memory controller chiplet, an I/O chiplet) that are then integrated together in a single advanced package (e.g., using 2.5D or 3D stacking).52 This improves manufacturing yield, reduces cost, and allows designers to mix and match chiplets fabricated in different process technologies.

Silicon photonics is emerging as the ideal interconnect fabric for these advanced chiplet-based systems. By using a photonic interposer or creating direct optical links between chiplets, SiPh can provide an ultra-high-bandwidth, low-latency, and power-efficient communication backbone for die-to-die communication within the package. This overcomes the physical limitations of copper wiring that can otherwise hinder the overall throughput of a chiplet-based system.7



4.3 Case Studies in Chiplet Innovation



The concept of OIO is being commercialized by innovative startups and standardized by industry consortia:

  • Ayar Labs TeraPHY: The TeraPHY is a leading example of a commercial OIO chiplet. It is a small, power-efficient electro-optical die that combines silicon photonics with standard CMOS electronics. Designed to be co-packaged alongside processors and accelerators, the TeraPHY provides multiple terabits-per-second of bidirectional bandwidth at an energy efficiency of less than 5 picojoules per bit (pJ/bit).21 A key feature is its reach-insensitivity; it provides this performance over distances ranging from millimeters (within a package) to kilometers (across a data center).21
  • The UCIe Standard: The Universal Chiplet Interconnect Express (UCIe) is a critical industry standard that defines an open, standardized die-to-die interconnect. The inclusion of optical I/O capabilities within the UCIe roadmap is a powerful signal of the industry’s consensus that optical solutions are necessary for the future of the chiplet ecosystem. Ayar Labs’ next-generation TeraPHY is designed to be UCIe compliant, ensuring interoperability and accelerating adoption.58



4.4 Enabling New Computing Paradigms: Disaggregation and Memory Pooling



The unique combination of high bandwidth, low latency, and long reach offered by OIO is not just an incremental improvement; it is an enabler of entirely new computing architectures. The most significant of these is disaggregation. In a disaggregated architecture, the tightly integrated components of a traditional server (CPU, GPU, memory, storage) are broken apart into physically separate, resource-specific pools that are interconnected by a high-speed optical fabric.21

This allows for unprecedented flexibility and efficiency in resource allocation. For example, a cluster of GPUs could directly access a massive, shared pool of high-bandwidth memory located in a different rack, without the high latency and low bandwidth penalties of a traditional network. This creates a memory-semantic fabric, where the optical interconnect behaves more like a system bus than a network.57 This paradigm effectively allows thousands of GPUs or other accelerators, spread across a data center, to function as a single, cohesive, giant computational unit. This is a crucial enabler for training the next generation of trillion-parameter AI models.57

The introduction of Optical I/O fundamentally transforms the economic and physical boundaries of what constitutes a “computer.” Traditionally, a single computing system has been defined by the components connected with very low-latency electrical traces on a motherboard. Communication outside this physical box, to another server, has always incurred a significant performance penalty via the network. OIO changes this by providing an interconnect with the bandwidth density and latency characteristics approaching those of on-package electrical traces, but with a reach of hundreds of meters.57 This means a GPU in one server can access a memory module in another server across the data center aisle with performance that feels “local.” This blurring of physical boundaries allows architects to design “rack-scale computers,” where resources are pooled and dynamically composed to meet the specific demands of a workload, breaking free from the rigid and inefficient server-box paradigm. This is a profound, third-order architectural shift that will require new operating systems, programming models, and software stacks to fully exploit its potential.

Section 5: The Silicon Photonics Ecosystem: Platforms, Players, and Production



The rapid maturation of silicon photonics from a research curiosity to a commercially vital technology has been driven by a complex and dynamic ecosystem of companies. This section provides a strategic analysis of the industrial landscape, mapping out the key entities—from the foundational foundries to the system integrators—that are collectively shaping the future of optical interconnects.



5.1 The Foundry Foundation: A Comparative Analysis



The ability to manufacture PICs at scale rests on the capabilities of a few specialized semiconductor foundries that have invested heavily in developing silicon photonics process technologies.

  • GlobalFoundries (GF): A key enabler of the “fabless photonics” model, GF offers its GF Fotonix™ platform. This is a monolithic platform that uniquely integrates photonic components, high-frequency RF-CMOS for drivers and amplifiers, and digital logic on a single 300mm silicon wafer.61 The platform is highly versatile, supporting data rates that have been upgraded to 200G per wavelength (
    200G/λ) and offering flexible Process Design Kits (PDKs) that are compatible with leading EDA tools from Ansys, Cadence, and Synopsys.63 GF is also investing in onshore, turnkey packaging and testing solutions, aiming to provide a complete “wafer-in, packaged-part-out” service to its customers.63 Their earlier
    9WG platform is based on a mature 90 nm SOI process, demonstrating a long-term commitment to the technology.35
  • TSMC: The world’s largest semiconductor foundry, TSMC is leveraging its unparalleled leadership in advanced packaging to enter the silicon photonics market. Their platform, named COUPE (COmpact Universal Photonic Engine), is built on their cutting-edge 3D stacking technology, SoIC (System on Integrated Chips).56 The COUPE approach involves fabricating the electronic IC (EIC) and the photonic IC (PIC) on separate wafers and then bonding them together with extremely dense, direct copper-to-copper connections. This 3D stacking enables the shortest possible electrical links between the electronics and photonics, maximizing performance and power efficiency. TSMC has demonstrated 200 Gbps modulation and high stacking yields on this platform and is projected to be in mass production with CPO technology by 2026, positioning it as a formidable force in the industry.65



5.2 The Titans of Industry: Strategic Approaches



Several established technology giants are pursuing distinct strategies to capitalize on the silicon photonics revolution.

  • Intel: A true pioneer in the field, Intel pursues a strategy of deep vertical integration. They control every step of the process: designing their own PICs, fabricating them in their own advanced fabs, developing unique technologies like integrated multi-wavelength lasers on silicon, and selling final products such as high-speed transceivers and OIO chiplets. This end-to-end control allows for deep co-optimization of the silicon, the components, and the final system, giving them a powerful competitive advantage.13
  • Cisco: As a leader in networking systems, Cisco has pursued a strategy of acquisition and integration. Rather than developing the core technology in-house from scratch, they acquired silicon photonics leader Luxtera in 2019. This move allowed them to rapidly incorporate best-in-class SiPh talent and intellectual property directly into their vast portfolio of switching and routing products, focusing on the system-level benefits and accelerating time-to-market.45
  • NVIDIA & Broadcom: These companies act as primary system-level drivers and integrators. They are at the forefront of designing the next-generation GPUs, switches, and AI accelerators that create the immense demand for CPO and OIO. They work in close partnership with foundries like TSMC and component suppliers to integrate silicon photonics into their flagship products, focusing on the profound architectural benefits that optical interconnects unlock for AI and HPC workloads.6



5.3 The Disruptors: Profiling Key Startups



A vibrant startup scene is a crucial part of the ecosystem, driving innovation in specific niches.

  • Ayar Labs: A leading fabless company focused exclusively on in-package optical I/O. Their flagship product, the TeraPHY chiplet, is designed to be the de facto standard for co-packaging with processors. Their strategy involves building a broad ecosystem by partnering with major chipmakers (Intel, NVIDIA), system builders, and foundries (GlobalFoundries) to ensure wide adoption and compatibility.21
  • Lightmatter: This startup is developing photonic interconnects and also exploring the more futuristic field of photonic computing. Their goal is to accelerate AI workloads with all-optical interfaces that promise dramatic improvements in performance and energy efficiency.70
  • Other key players identified in market analyses include Rockley Photonics (with a strong focus on sensing applications), MACOM, and Lumentum, each carving out specific roles in the supply chain.45

The evolution of the silicon photonics industry is mirroring the history of the broader semiconductor market, leading to the emergence of a robust “Fabless Photonics” model. Building and operating a state-of-the-art fab capable of producing silicon photonics is a multi-billion dollar endeavor, creating an insurmountable barrier to entry for most companies. This led to the highly successful fabless model in electronics, where companies like NVIDIA and Broadcom focus on chip design and partner with specialized foundries like TSMC for manufacturing. The same dynamic is now firmly established in photonics. Foundries like GlobalFoundries and TSMC are offering increasingly mature and feature-rich SiPh PDKs, which provide standardized, pre-validated building blocks and design rules.63 This critical enablement allows fabless startups like Ayar Labs to focus their resources entirely on the design, architecture, and system-level innovation of their optical I/O chiplets, without the massive capital expenditure of building a fab. This model democratizes access to the technology, lowers the barrier to entry, and is a powerful catalyst for accelerating innovation across the entire industry.

Company/Entity Category Key Platform/Product Strategic Focus/Market Position
GlobalFoundries Foundry GF Fotonix™, 9WG Monolithic SiPh+RF CMOS integration, turnkey solutions, enabling the fabless ecosystem.
TSMC Foundry COUPE (Compact Universal Photonic Engine) 3D stacking (SoIC) for ultimate EIC+PIC integration, leveraging advanced packaging leadership.
Intel Vertically Integrated Giant SiPh Transceivers, Optical I/O Chiplets End-to-end control from design to high-volume manufacturing in own fabs; deep vertical integration.
Cisco Vertically Integrated Giant Networking Switches & Routers System-level integration through strategic acquisition of SiPh IP and talent (e.g., Luxtera).
NVIDIA System Integrator/Driver GPUs, Quantum/Spectrum Switches Driving demand for CPO and OIO to enable next-generation AI/HPC architectures.
Broadcom System Integrator/Driver Tomahawk Switches, XPUs Early adopter and producer of CPO systems for AI networks, focusing on high-volume deployment.
Ayar Labs Fabless Innovator/Startup TeraPHY™ Optical I/O Chiplet Establishing an ecosystem for in-package optical I/O; UCIe standardization.
Lightmatter Fabless Innovator/Startup Passage Interconnect, Photonic Computing Developing optical interconnects and processors to accelerate AI workloads.
imec Research Institution Advanced R&D, Prototyping Pioneering next-generation devices, materials, and integration techniques; industry collaboration hub.

Table 2: An overview of the key players in the silicon photonics ecosystem, categorized by their primary role and strategic focus. Information is synthesized from multiple sources.6

Section 6: Critical Challenges on the Path to Ubiquity



Despite its immense promise and rapid progress, silicon photonics is not yet a plug-and-play technology. Several significant technical and economic hurdles must be systematically addressed to enable its widespread, cost-effective deployment. The primary battleground for competitive advantage has shifted from demonstrating novel device physics in a lab to solving the hard engineering problems of manufacturing, packaging, and testing these devices reliably and cheaply at massive scale.



6.1 The Manufacturing Gauntlet: Fabrication, Packaging, and Test



  • Light Source Integration: As detailed previously, the inability of silicon to lase efficiently necessitates the integration of III-V materials. This remains a central manufacturing challenge. Both hybrid (die-bonding) and heterogeneous (wafer-bonding) approaches involve joining dissimilar materials with different crystal lattices and thermal expansion coefficients, which can introduce defects, impact long-term reliability, and add significant complexity and cost to the fabrication process.31
  • Packaging and Assembly: This is widely considered the single greatest bottleneck and cost driver for the commercialization of silicon photonics.8 The core problem is
    fiber-to-chip coupling. A standard single-mode optical fiber has a core diameter of about 9 µm, while a silicon waveguide has cross-sectional dimensions of a few hundred nanometers. Efficiently transferring light between these two vastly different scales requires alignment with sub-micron precision. The current state-of-the-art often relies on active alignment, a process where the device is powered on and the fiber is moved by high-precision robotics until the optical throughput is maximized, at which point it is fixed in place with epoxy. This process is slow, serial, and extremely expensive, making it unsuitable for high-volume manufacturing.8 The industry is aggressively pursuing
    passive alignment techniques, which use lithographically defined features like V-grooves and spot-size converters to guide the fiber into place without needing to power on the device, a critical step for achieving scalable, low-cost assembly.63
  • Wafer-Level Test: In electronics manufacturing, comprehensive testing is performed at the wafer level to identify faulty dies before they are packaged, which saves significant cost. Testing PICs at the wafer level is far more complex. It requires bringing optical probes (fibers or grating couplers) into contact with the wafer to inject and extract light, a process that is much more challenging and less mature than electrical probing. This difficulty in obtaining high-throughput, wafer-scale test data complicates yield analysis, process control, and ultimately, cost management.27



6.2 The Thermal Threat: Managing Temperature Sensitivity



Photonic devices are notoriously sensitive to temperature, a characteristic that presents a major challenge, especially in co-packaged applications.

  • High Thermo-Optic Coefficient: Silicon has a large thermo-optic coefficient, meaning its refractive index changes significantly with temperature.8 This is the very property that enables efficient thermal tuning, but it is also a major liability.
  • Component Detuning and Thermal Crosstalk: Wavelength-sensitive components like microring resonators and arrayed-waveguide gratings (AWGs) rely on precise, fixed refractive indices to function correctly. A small change in temperature can shift their operating wavelength, causing them to detune and leading to signal degradation or complete link failure.76 In a CPO or OIO scenario, the hundreds of watts of waste heat generated by the co-packaged electronic ASIC can easily raise the temperature of the PIC, creating large thermal gradients and causing severe performance issues. This thermal crosstalk between the hot electronics and the sensitive photonics is a critical multi-physics design challenge.52
  • Mitigation Strategies: The common solution is active thermal management. Integrated micro-heaters are used to locally tune and stabilize the temperature of critical components, compensating for ambient temperature changes and fabrication variations. However, these heaters consume additional power, adding to the system’s energy budget and design complexity.7 Advanced research is focused on novel packaging solutions that incorporate microfluidic cooling, thermal isolation trenches etched into the silicon substrate to prevent heat from spreading, and materials with better thermal conductivity to more efficiently dissipate heat.55



6.3 The Economics of Scale: Driving Down Costs



While the core value proposition of silicon photonics is low cost at high volume, achieving that goal is contingent on overcoming several economic hurdles.

  • High Initial Costs: The non-recurring engineering (NRE) costs associated with designing a PIC and creating the necessary photomask sets for a foundry run are substantial. These high upfront costs can be a barrier for startups and for applications with lower volume projections.78
  • Back-End Cost Dominance: As noted, the complex and often manual back-end processes of packaging, assembly, and testing currently dominate the total cost of a packaged photonic device, sometimes accounting for as much as 80% of the final cost.4 The cost of the silicon die itself can be relatively small in comparison.
  • Path to Cost Reduction: The path to making silicon photonics cheaper than advanced copper solutions requires a multi-pronged effort: standardization of interfaces and packaging formats, heavy investment in the automation of assembly and testing processes, and sufficient market volume to amortize the high fixed costs of the foundry model.25

The fundamental components of silicon photonics—the modulators, detectors, and waveguides—are now well-understood and can be reliably fabricated. The primary battleground for competitive advantage and commercial success has therefore shifted. It is now centered on the development of the processes, tools, and engineering techniques required to build, package, and test these components reliably, repeatedly, and cheaply at the massive scale demanded by the data center market. The companies that master the hard engineering of automated optical alignment, wafer-level testing, and multi-physics thermal co-design will be the ones who can deliver on the cost and performance promises of silicon photonics and will ultimately win the market.

Challenge Area Specific Problem Current State-of-the-Art Solutions Key Research Directions
Light Source Integration Silicon’s indirect bandgap prevents efficient light emission. Hybrid integration (flip-chip bonding) of III-V laser dies; Heterogeneous (wafer-bonding) integration. Improved wafer-bonding techniques; Direct epitaxial growth of quantum dot (QD) lasers on silicon.
Packaging & Assembly Sub-micron alignment precision required for fiber-to-chip coupling is slow and expensive. Active alignment (power-on, robotic positioning); Grating couplers for vertical coupling. High-throughput passive alignment techniques (V-grooves); Wafer-level packaging; Detachable fiber attach.
Thermal Management High thermo-optic coefficient of silicon leads to thermal detuning and crosstalk from co-packaged electronics. Integrated micro-heaters for active thermal tuning and stabilization; Thermoelectric coolers (TECs). Advanced cooling (microfluidics); Thermal isolation trenches in the substrate; Athermal device designs.
Fabrication & Cost High NRE costs; Complex back-end (packaging, test) processes dominate the final device cost. Leveraging mature 300mm CMOS foundry scale; Multi-project wafer (MPW) runs for prototyping. High-throughput, automated wafer-level optical testing; Standardization of design and packaging.

Table 3: A summary of the key technical and manufacturing challenges facing the silicon photonics industry, outlining the core problems, current solutions, and future research directions.8

Section 7: The Competitive and Collaborative Landscape



The emergence of silicon photonics does not mean the immediate obsolescence of all other interconnect technologies. Rather, the market is stratifying, with different technologies finding their optimal niche based on a complex trade-off between performance, cost, and application requirements. This section provides a comparative analysis of silicon photonics against its primary competitors and collaborators, painting a nuanced picture of a future heterogeneous interconnect landscape.



7.1 A Tale of Two Platforms: Silicon Photonics vs. Indium Phosphide (InP)



Indium Phosphide (InP) is the other major material platform for Photonic Integrated Circuits and has historically been the technology of choice for high-performance optical communications.

  • InP Strengths: As a direct-bandgap semiconductor, InP is inherently superior for all active optical functions. It can efficiently generate light (lasers), amplify light (semiconductor optical amplifiers, or SOAs), and modulate light (via the efficient electro-optic effect).19 This allows for the creation of fully monolithic PICs where all components, including the light source, are integrated on a single InP chip. This makes InP the undisputed platform of choice for the most demanding applications, such as long-haul and metro coherent communication systems, which require the highest levels of performance and integration.19
  • Silicon Photonics Strengths: The advantage of SiPh is not in the intrinsic optical properties of its material but in its manufacturing paradigm. Leveraging the massive, mature, and cost-effective 300mm CMOS ecosystem allows SiPh to produce very large and complex PICs at a scale and cost that InP, which is typically fabricated on smaller and more expensive 3- or 4-inch wafers, cannot match.19
  • The Verdict: Segmentation, Not Replacement: The relationship between SiPh and InP is best understood as a market segmentation rather than a head-to-head battle. InP will continue to dominate the high-performance, high-margin niches where its superior optical capabilities are essential (e.g., coherent transceivers for >120 Gbaud rates).19 Silicon photonics, with its compelling cost structure at high volumes, is capturing the massive data center interconnect market (for intra-data center links) and the emerging chip-to-chip communication space. The most powerful solutions often involve a
    hybrid approach, combining the best of both worlds by heterogeneously integrating high-performance InP-based lasers onto large, complex, and low-cost silicon photonic circuits.19



7.2 Emerging Alternatives: The Potential of Polymer Photonics



Polymer photonics is an emerging technology that uses specialized polymer materials to create optical components like waveguides.

  • Polymer Strengths: The primary advantages of polymer photonics are its potential for very low-cost manufacturing, mechanical flexibility, and simple processing techniques, such as direct-write lithography.20
  • Role and Application: While polymers do not currently offer the performance or integration density of silicon for creating complex active PICs, they are emerging as a highly valuable complementary technology, particularly for packaging and board-level interconnects. Researchers have developed polymer materials that can be used to “print” low-loss optical interconnects directly onto a circuit board or between chips, potentially simplifying the difficult fiber-to-chip alignment process and providing a flexible, low-cost method for board-level optical wiring.20



7.3 The Future of Copper: Coexistence with Optics



Despite the clear advantages of optics for longer-reach, high-bandwidth links, advanced copper interconnects will not disappear. For very short-reach connections—on the scale of millimeters to a few centimeters, such as between chiplets on a silicon interposer or across a motherboard—the extremely low latency and simplicity of a direct electrical trace remain highly competitive.2 The power consumption for such short links is manageable, and they avoid the overhead of O/E and E/O conversion.

The future interconnect landscape will therefore be a heterogeneous one, where the optimal technology is chosen based on the specific requirements of the link. A typical advanced server might use:

  • Advanced copper links for ultra-short, latency-critical die-to-die communication on an interposer.
  • Silicon photonics (OIO) for high-bandwidth chip-to-memory or chip-to-chip communication across a package or board.
  • Silicon photonics (AOCs or CPO) for rack-to-rack communication within the data center.
  • InP-based coherent optics for long-haul communication between data centers.9

This stratification of the interconnect market is a direct consequence of the fundamental physics and economics governing each technology. There is no single “winner” that can optimally address the vastly different trade-offs between cost, power, latency, and bandwidth at every length scale. A clear hierarchy is forming: advanced copper for the millimeter-to-centimeter domain, silicon photonics for the centimeter-to-kilometer range in high-volume applications, and Indium Phosphide for specialized, high-performance links spanning tens to thousands of kilometers. This requires companies to make strategic choices about which technology to develop and which market segment to target, as expertise in one area does not guarantee success in another.

Section 8: Future Trajectory and Strategic Outlook



Synthesizing the technological capabilities, market drivers, and industrial challenges, the future trajectory for silicon photonics is one of accelerating adoption and deepening integration into the core of the computing architecture. This final section projects the roadmap for the technology and its transformative impact on the future of communication and computation.



8.1 The Symbiosis of AI and Photonics: Enabling Exascale AI



The single largest demand driver for silicon photonics is, and will continue to be, the exponential growth in the scale and complexity of artificial intelligence models.17 Training and running large language models (LLMs) and other generative AI systems requires massive, distributed clusters of thousands of accelerators (GPUs or custom ASICs). The performance of these clusters is increasingly limited not by the computational speed of the individual chips, but by the bandwidth and latency of the interconnects that link them together.16

Generative AI clusters require 10 to 100 times more fiber interconnect bandwidth than traditional cloud services, pushing copper interconnects far beyond their physical limits.17 Silicon photonics, through CPO and OIO, provides the necessary scale-out connectivity. This relationship is symbiotic: AI provides the “killer application” that justifies the massive investment in silicon photonics, while silicon photonics provides the “enabling infrastructure” that will allow AI models to continue their exponential scaling. In the near future, AI accelerators will be designed from the ground up with optical I/O as a native, integral feature. This will lead to a co-evolution of AI algorithms, hardware architectures, and photonic technologies, with each discipline influencing and enabling advances in the others.25



8.2 The Long-Term Vision: The Quest for All-Photonic Networks-on-Chip (ONoCs)



While the current focus is on replacing off-chip and off-package electrical wires, the ultimate long-term vision is to bring light even deeper into the chip itself. The goal is to replace the global on-chip electrical interconnects—the “wires” that connect different cores and caches within a single processor—with an Optical Network-on-Chip (ONoC).83

An ONoC would use nanoscale waveguides, optical switches, and modulators to route data between cores at the speed of light. This promises to eliminate the on-chip communication bottleneck entirely, offering near-zero latency for long-distance on-chip communication and a power consumption that is largely independent of distance.83 This would be a revolutionary step, enabling the creation of many-core processors with thousands of cores that can communicate as efficiently as if they were adjacent to one another. While this remains a formidable research challenge requiring breakthroughs in nanoscale, low-power optical switches and routers, major long-term research initiatives, such as NTT’s IOWN (Innovative Optical and Wireless Network), are actively developing the foundational technologies to make this vision a reality.83



8.3 Market Projections and Concluding Analysis



The commercial outlook for silicon photonics is exceptionally strong. Market analyses consistently project a compound annual growth rate (CAGR) of approximately 25-30%, with the market expected to grow from around $2.2 billion in 2024 to nearly $10 billion by 2030 and over $43 billion for data center transceivers alone by 2035.44 This growth will be driven initially by the continued adoption of high-speed pluggable transceivers, followed by a major wave of growth from CPO and OIO solutions as they become mainstream in AI and HPC systems.

Strategic Conclusion:

Silicon photonics has successfully navigated the perilous journey from academic research to commercial reality. It is no longer a speculative, future technology; it is a foundational, commercially viable platform that is actively being deployed at scale and is central to the strategic roadmaps of every major company in the computing and networking industries. The physical and economic limits of copper have made the transition to optical interconnects an inevitability. Silicon photonics, with its unique and powerful combination of optical performance and CMOS-scalability, stands as the only technology capable of delivering on the cost and volume requirements of this massive market shift.

The challenges that remain—particularly in packaging and thermal management—are significant engineering problems, but they are problems of “how,” not “if.” The industrial ecosystem is rapidly maturing, the design tools are becoming more sophisticated, and the economic drivers are overwhelmingly strong. Therefore, all stakeholders in the technology value chain, from investors and equipment suppliers to system architects and software developers, must formulate their strategies with the clear understanding that the future of high-performance data communication will be defined not by the flow of electrons, but by the propagation of light.
