Part 1: The End of the Silicon Era and the Rise of Quantum-Scale Devices

Executive Summary: The Two “Quantum” Revolutions

Next-generation processors are redefining computing through atomic-level switching, quantum-effect devices, and post-silicon manufacturing innovations.

The semiconductor industry is at a foundational inflection point. For half a century, its trajectory has been defined by the predictable scaling of the silicon-based metal-oxide-semiconductor field-effect transistor (MOSFET).1 This scaling, however, is colliding with fundamental physical and economic limits. In response, the industry is diverging onto two distinct “beyond-silicon” trajectories, both of which are frequently and confusingly labeled “quantum.” This report will disambiguate these two paths, analyze their underlying technologies, and provide a strategic forecast for the future of computation.

It is a common misconception that quantum mechanics is new to electronics; in fact, all modern computing is “quantum” in nature. The very existence of energy bands, semiconductivity, and the operation of the first diodes and transistors are phenomena only explainable by quantum mechanics.2 The current shift, however, is one of intent. Instead of building devices that operate despite certain quantum effects (like leakage), engineers are now designing devices that explicitly leverage specific quantum phenomena to function.

https://uplatz.com/course-details/bundle-combo-data-science-with-python-and-r/414

These two divergent paths are:

  1. Path 1: The Quantum-Effect Classical Switch. This is the pursuit of a “better switch” to continue the roadmap for classical computing (e.g., high-performance computing (HPC), mobile, and Internet of Things (IoT)). This path leverages quantum-mechanical principles like quantum tunneling and Coulomb blockade to create a more efficient binary (0/1) transistor. The goal is to overcome the fundamental power and scaling limitations of the silicon MOSFET. This domain includes Tunnel Field-Effect Transistors (TFETs), Single-Electron Transistors (SETs), Carbon Nanotube FETs (CNFETs), and 2D-material FETs.3
  2. Path 2: The True Quantum Processor. This is the pursuit of a “new computer” based on a different computational paradigm. This path leverages the quantum-mechanical properties of superposition (where a “qubit” can be 0 and 1 simultaneously) and entanglement to perform calculations.6 In this context, the “transistor” has been repurposed in two ways: either as the qubit itself (e.g., a silicon FinFET structure used to trap a single electron) or as an ultra-sensitive readout sensor (e.g., an SET) for the qubit.8

This report will analyze the physics, materials, manufacturing, and architectural implications of both paths. It will demonstrate that the future of computation is not a replacement but a hybridization, where these two paths will ultimately converge in 3D-heterogeneously integrated systems.



The Scaling Imperative: Beyond the Boltzmann Tyranny



The primary driver for this paradigm shift is the failure of classical silicon scaling. The silicon MOSFET, the workhorse of the digital age, has hit a fundamental physical wall.1



The Physics Wall: The “Boltzmann Tyranny”



The classical transistor is a thermal device. It operates by using a gate voltage to lower an energy barrier, allowing electrons to “boil” over it via thermionic emission—a process driven by thermal energy.3 This thermal mechanism imposes a fundamental limit on the transistor’s “steepness,” or how sharply it can switch from “off” to “on.”

This limit is known as the subthreshold swing (SS), which measures the gate voltage ($V_G$) required to increase the drain current ($I_D$) by one decade (a factor of 10). At room temperature, the physics of thermionic emission dictates a minimum theoretical SS of 60 millivolts per decade (mV/dec).3 This is the “Boltzmann tyranny”.11

For decades, this was not a problem. But as transistors shrink, their supply voltage ($V_{DD}$) must also be reduced to manage power density and heat.4 With a “floor” of 60 mV/dec on the switching steepness, it becomes impossible to scale $V_{DD}$ below a certain point (e.g., sub-0.5V) and still have the transistor turn “off” completely.4 The result is a massive, exponential increase in static leakage current, which now accounts for a significant portion of a chip’s total power consumption.12 This has led to the “dark silicon” problem, where large portions of a chip must be kept powered down to avoid meltdown.13 To continue scaling, a new device is required—one whose switching mechanism is not thermal and can, therefore, achieve a “super-steep” SS (sub-60 mV/dec).3



The Economic Wall: Rock’s Law



Parallel to this physics crisis is an economic one. Moore’s Law—the observation that transistor density doubles at a predictable cadence—is enabled by its “darker side,” Rock’s Law.14 Rock’s Law states that the cost of the semiconductor fabrication plant (fab) required to produce these chips rises exponentially with each generation.14

This is the price of pushing matter to atomic precision. A state-of-the-art fab now costs between $10 billion and $20 billion.14 A single High-NA Extreme Ultraviolet (EUV) lithography scanner, the most advanced patterning tool, costs over $400 million.14

The industry is therefore trapped in a “CMOS Pincer”:

  1. The physics of the MOSFET (Boltzmann Tyranny) demands a revolutionary new device.3
  2. The economics of the fab (Rock’s Law) demands that this new device be CMOS-compatible, meaning it must be manufacturable using the existing, multi-trillion-dollar infrastructure.14

This economic “activation energy” is the primary filter for all “beyond silicon” candidates. The industry’s formal acknowledgments of this crisis, such as the U.S. Department of Energy’s “Energy Efficiency Scaling for Two Decades” (EES2) roadmap and the International Roadmap for Devices and Systems (IRDS), are actively scouting for CMOS-compatible replacements, with TFETs, CNFETs, and 2D materials as prime candidates.15



Part 2: The Next Classical Transistor: Devices Based on Quantum-Mechanical Principles



This section analyzes the leading candidates for Path 1: a “better switch” that leverages quantum mechanics to overcome the 60 mV/dec limit and replace the classical MOSFET.



Tunnel Field-Effect Transistors (TFETs): Breaking the Thermal Limit



The Tunnel Field-Effect Transistor (TFET) is the most direct challenger to the MOSFET’s physical limitations.



Principle of Operation



Unlike a MOSFET, which relies on thermionic emission over a barrier, the TFET is a pure quantum-mechanical switch.3 It operates by using the gate voltage to modulate the Band-to-Band Tunneling (BTBT) of electrons through an energy barrier.4

In the “off” state, the conduction and valence bands are misaligned, and no tunneling is possible. As gate voltage is applied, the bands are shifted, and a “tunneling window” opens, allowing electrons to quantum-tunnel from the source’s valence band to the channel’s conduction band.3 Because this switching mechanism is non-thermal, its subthreshold swing is not limited by the 60 mV/dec “Boltzmann” limit.12 This allows for a “super-steep” SS and, in theory, a dramatic reduction in standby power consumption by enabling ultra-low supply voltages.4



The Primary Challenge: The “TFET Trade-off”



For years, TFETs have been stalled by a fundamental trade-off: while they are excellent at being “off” (low leakage), the quantum tunneling effect is a low-probability event. This results in an inherently low ON-current ($I_{on}$).20 This low drive current makes them too slow for high-speed computation, relegating them to niche low-power applications. The central goal of TFET research is to solve this low $I_{on}$ problem while retaining the steep SS.



Breakthrough 1: The Negative Capacitance (NC-FET) “Hack”



A major breakthrough has been the development of the Negative Capacitance TFET (NC-TFET).22 This is a hybrid device that integrates a thin layer of ferroelectric material (such as PZT or silicon-doped HfO$_2$) into the gate stack.22

This ferroelectric material exhibits a “negative capacitance” (NC), an unstable state that can be stabilized when paired with the positive capacitance of the transistor gate.22 The profound result is an internal voltage amplification effect.22 A small change in the external gate voltage (e.g., 10 mV) is “stepped-up” by the ferroelectric layer, applying a much larger effective voltage (e.g., >60 mV) directly to the TFET’s tunneling junction.22

This is a “physics hack” that accomplishes two things simultaneously:

  1. It provides a super-steep external SS, with experimental values demonstrated down to 10 mV/decade.22
  2. It dramatically boosts the tunneling probability by applying a much larger internal electric field, solving the low $I_{on}$ problem.22

This NC-TFET concept, which combines the NC effect with the BTBT mechanism, represents one of the most promising paths to a high-performance, super-steep transistor.22



Breakthrough 2: The 2D Materials Solution



A parallel solution to the TFET’s $I_{on}$ problem lies in materials science. TFET performance is highly dependent on creating an abrupt junction and an intense electric field at the tunneling point.20 Atomically-thin two-dimensional (2D) materials, particularly Transition Metal Dichalcogenides (TMDs) like MoS$_2$ and WSe$_2$, are the ideal channel material for this.23

This material-device synergy is critical. The atomic-scale thickness of 2D TMDs (as thin as three atoms) provides the “ultimate” electrostatic integrity, allowing the gate to exert perfect, “tight” control over the channel and induce the sharp band-bending needed for efficient tunneling.21

Furthermore, TFETs perform best as heterojunctions (junctions of two different semiconductor materials) to engineer the band alignments for tunneling.26 Stacking different 2D materials (e.g., a WSe$_2$/MoS$_2$ junction) creates a “van der Waals heterojunction”.28 Unlike 3D junctions (e.g., SiGe-on-Si), these 2D-stacked junctions are atomically clean and free of the lattice-mismatch defects that kill device performance.26

This combination—perfect electrostatics (from 2D thinness) and perfect junctions (from 2D stacking)—is the key to fabricating high-performance TFETs that solve the low $I_{on}$ problem.26 Research into MoS$_2$-based TFETs has demonstrated their potential for sub-60mV/dec performance, and a trade-off analysis between monolayer and multilayer MoS$_2$ shows that while monolayers give the best SS, multilayers (e.g., 6-layer) can provide a higher ON-current.29 These 2D TFETs have already been used to demonstrate basic VLSI circuits like inverters and half-adders.33



Single-Electron Transistors (SETs): The Ultimate Scaling Limit



The Single-Electron Transistor (SET) represents the theoretical ultimate limit of transistor scaling, a device that operates by controlling the flow of one electron at a time.34



Principle of Operation: The Coulomb Blockade



An SET is a three-terminal device where a small conductive “island,” or quantum dot, is separated from the source and drain electrodes by two thin tunnel junctions.34 Its operation is governed by a quantum-mechanical phenomenon called the Coulomb blockade.34

The act of adding a single electron to the tiny island requires a specific amount of charging energy ($E_C = \frac{e^2}{2C}$), where $C$ is the island’s tiny self-capacitance.34 If the incoming electron’s energy (from thermal energy $k_B T$ or bias voltage $V_{bias}$) is less than this charging energy, the electron is “blocked,” and no current can flow. This is the “off” state.34

The gate electrode is capacitively coupled to the island and is used to precisely tune the island’s electrochemical potential.34 By applying a specific gate voltage, the blockade can be lifted, allowing exactly one electron to tunnel onto the island, and then tunnel off to the drain. The blockade is then re-established until the next cycle. Current flows in this discrete, one-by-one fashion.34



Analysis: The “Wrong Tool” for Logic, The “Right Tool” for Sensing



While the SET is a marvel of physics, it is a poor candidate for general-purpose logic. The conditions for observing the Coulomb blockade are severe:

  1. Cryogenic Operation: The thermal energy must be much lower than the charging energy ($k_B T \ll \frac{e^2}{2C}$), which for practical devices means operation at liquid helium or millikelvin temperatures.34
  2. Low Speed: To ensure the electron is properly “confined” to the island, the tunnel barriers must have high resistance ($R_t \gg \frac{h}{e^2} \approx 25.8 k\Omega$), which inherently limits the current and thus the switching speed.34
  3. Noise Sensitivity: The device’s state is controlled by a single electron. This makes it exquisitely sensitive to any stray background charges or “charge noise,” a critical problem in a dense chip environment.

This analysis reveals a critical pivot. The SET’s “weakness” as a logic device—its extreme sensitivity to its electrostatic environment—is its greatest strength as a sensor. This makes the SET the leading technology for the high-fidelity, non-destructive readout of a quantum qubit’s state, a concept central to Part 4 of this report.10



Atomic and Molecular-Scale Switches: The Research Frontier



The absolute frontier of “Path 1” involves fabricating switches from single atoms or molecules. These devices are not just smaller transistors; they are fundamentally different computational elements.



The Single-Atom Transistor



In a landmark experiment, researchers fabricated a transistor where the active component was a single phosphorus (P) dopant atom deterministically placed within a silicon crystal.36

The fabrication process itself is a technological marvel, relying on Scanning Tunneling Microscope (STM) lithography.37

  1. A silicon (Si(100)) surface is passivated with a “resist” layer of hydrogen atoms.37
  2. The tip of an STM is used to “write” a pattern by selectively desorbing individual hydrogen atoms, exposing the reactive silicon dangling bonds underneath with atomic precision.37
  3. The chamber is exposed to phosphine ($\text{PH}_3$) gas. The $\text{PH}_3$ molecules stick only to the desorbed patches.37
  4. A brief thermal anneal incorporates the phosphorus atom into the silicon lattice at that precise location.37

This technique was used to place a single P atom between two heavily-doped silicon leads, creating a functional single-atom transistor.37 This was also demonstrated for creating SETs with atomically precise tunnel gaps.39



The Single-Molecule Transistor (Quantum Interference)



A more recent breakthrough, published in Nature Nanotechnology in March 2024, demonstrated a transistor where the conductive channel is a single molecule (a zinc porphyrin molecule) sandwiched between two graphene electrodes.42

The switching mechanism in this device is not a thermal barrier (MOSFET) or a tunneling barrier (TFET). Instead, it relies on quantum interference.42 The gate voltage is used to control the phase of the electron’s wavefunction as it passes through the molecule. By tuning the gate, the electron’s pathways can be made to interfere constructively (the “on” state, with high current) or destructively (the “off” state, where the electron’s wavefunction cancels itself out, leading to very low current).42



Implications: Beyond Binary Computation



These atomic-scale devices reveal a new computational paradigm. The single-atom transistor’s transport measurements (at cryogenic temperatures) show discrete quantum energy levels, not a simple binary on/off state.36 The single-molecule transistor operates on wave interference, an analog phenomenon.

This behavior—multi-state, analog, or wave-based—is a poor fit for traditional binary logic. However, it is exactly what is required for non-von Neumann computing architectures, which will be discussed in Part 5. These devices are ideal candidates for building hardware-based neuromorphic computers (which seek to emulate the analog, multi-level “synaptic” behavior of a biological neuron) and in-memory computing systems.43

Table 1: Comparative Analysis of “Beyond Silicon” Transistor Candidates (For Classical Logic)



Device Operating Principle Key Metric Primary Advantage Primary Challenge Key Materials TRL
FinFET (Baseline) Thermionic Emission 1 SS $\approx$ 60-70 mV/dec Mature, Scalable (EUV) Power/Leakage (Boltzmann Tyranny) 3 Silicon, SiGe 9
TFET Band-to-Band Tunneling (BTBT) 3 SS < 60 mV/dec 19 Ultra-low standby power Low ON-current ($I_{on}$) 20 Si, Ge, III-V 5-6
NC-TFET BTBT + Negative Capacitance 22 SS < 10 mV/dec 22 “Super-steep” slope, high $I_{on}$ Complex material stack, reliability III-V/2D-TMD + HfO$_2$, PZT 22 4-5
SET Coulomb Blockade 34 Single-electron switching Ultimate scaling, high sensitivity Cryogenic, low current, noise sensitive 34 Silicon, GaAs 3 (for logic); 6 (for sensors)
CNFET Ballistic Transport 45 7-10x Energy-Delay Product 46 Highest speed & energy efficiency Material purity, placement density 5 Carbon Nanotubes (CNTs) 6-7 (VLSI demo)
2D-TMD FET Thermionic Emission SS $\approx$ 60 mV/dec Ultimate thickness (no SCEs) 24 Wafer-scale growth, contact resistance MoS$_2$, WSe$_2$ 23 5-6

Part 3: The “New Silicon”: Materials and Fabrication at the Atomic Scale



The success of any new transistor (Path 1) or qubit (Path 2) is entirely dependent on the ability to manufacture it at scale. This requires a new generation of materials and fabrication techniques that bridge the gap from lab-scale prototypes to 300mm wafer production.



Carbon Nanotube Field-Effect Transistors (CNFETs): The “Drop-In” Successor



The Carbon Nanotube Field-Effect Transistor (CNFET) has emerged as the leading “drop-in” replacement for silicon in high-performance logic.



The Promise



A carbon nanotube is a sheet of graphene (a 1-atom-thick hexagonal lattice of carbon) rolled into a cylinder.49 As a transistor channel, this quasi-one-dimensional structure is near-perfect:

  • Ballistic Transport: Electrons can travel through the nanotube without “scattering” off the lattice, which is the primary source of resistance in silicon.45
  • Ideal Electrostatics: The ~1 nm diameter of the nanotube is an “ultrathin body,” giving the gate perfect electrostatic control and immunity to the short-channel effects that plague silicon.46
  • High Mobility: CNFETs exhibit superior charge transport, delivering higher current densities than silicon.46

The combined result is a device that promises 7x to 10x improvements in the critical energy-delay product (EDP), meaning dramatically faster and more energy-efficient computation.46



The Twin Challenges and the MIT/Stanford Breakthrough



For nearly two decades, CNFETs were a lab curiosity, stalled by two “show-stopper” manufacturing problems 5:

  1. The Purity Problem: Standard synthesis methods produce a random mix of semiconducting nanotubes (which are useful for transistors) and metallic nanotubes (which act as a short circuit, killing the transistor’s “off” state).5
  2. The Placement Problem: It was impossible to deposit dense, perfectly aligned arrays of nanotubes onto industry-standard wafers.45

Research groups at MIT and Stanford, in a series of foundational breakthroughs, systematically solved these problems. They developed processing techniques to remove the metallic CNTs and invented a scalable “solution-based incubation” method that allows for the high-density deposition of CNTs on 200mm wafers.5



The Proof: The RV16X-NANO Microprocessor



The culmination of this research was the RV16X-NANO, a 16-bit microprocessor built entirely from CNFETs.5 This was not a single-device demo; it was a complex system comprising more than 14,000 CNFETs, based on the open-source RISC-V instruction set.5

The true significance of the RV16X-NANO was not the chip itself, but its manufacturing process. It was designed using industry-standard design flows and fabricated in a commercial silicon manufacturing facility.5

This demonstration single-handedly proved that CNFETs are not a far-off dream. By validating their compatibility with existing CMOS fabrication infrastructure, the RV16X-NANO team solved the “Rock’s Law” side of the CMOS Pincer (from Part 1). This makes CNFETs the leading candidate for a “drop-in” (or, more likely, a 3D-stackable) replacement for silicon logic.



2D Materials: A New Toolbox for Device Engineering



The other major material class is 2D materials, which are atomically-thin crystalline layers.

  • Graphene: The original “miracle material”.56 Graphene’s exceptional electron mobility (10x higher than silicon) promised unprecedented speeds.56 However, it has a fatal flaw for logic: it has no bandgap.57 This means a graphene transistor can never be fully turned “off,” leading to massive leakage.57 Its true future lies in applications that do not require a bandgap, such as high-frequency interconnects (replacing copper) 58, transparent electrodes (as used in the molecular transistor) 42, and specialized sensors.59
  • Transition Metal Dichalcogenides (TMDs): This family of materials (e.g., MoS$_2$, WSe$_2$, MoTe$_2$) represents the solution to graphene’s flaw.23 TMDs do have intrinsic, tunable bandgaps.25 Their defining feature is their atomic thinness (~0.65 nm for a monolayer).24 A transistor channel made of monolayer MoS$_2$ is the thinnest possible, providing perfect electrostatic control and eliminating all “short-channel effects” (SCEs) that plague scaled silicon.24

The future is not “a 2D chip” but a hybrid chip. 2D materials are not a monolithic replacement for silicon; they are a heterogeneous toolbox. A future high-performance chip will be a 3D-stacked “monolithic” system: silicon for the base logic, graphene for the interconnects, and stacked “floors” of 2D TMDs (e.g., MoS$_2$ nFETs and WSe$_2$ pFETs 48) used for TFETs (as in Part 2) or to add new layers of logic and memory directly on top of the silicon.61



Manufacturing the Atomic Scale: From EUV to DSA



The transition to these new devices and materials requires a complete overhaul of manufacturing philosophy, moving from “top-down” patterning to “bottom-up” atomic assembly.



The “Top-Down” Limit: EUV Lithography



The current state-of-the-art is Extreme Ultraviolet (EUV) lithography, which uses 13.5 nm wavelength light to pattern features.63 This technology is an engineering marvel but is being pushed to its absolute limits. Its challenges are immense:

  • Reflective Optics: 13.5 nm light is absorbed by everything, including air and glass lenses. This forces EUV systems to operate in a perfect vacuum and use hyper-complex reflective masks and mirrors.64
  • Mask Defects: The masks are made of 70+ alternating layers. A single defect buried deep within this stack is undetectable but can be “printed” onto the wafer, catastrophically destroying thousands of chips.65
  • Stochastic Effects: At the sub-10 nm scale, the (already low) number of photons from the EUV source creates “photon shot noise,” leading to random, non-deterministic patterning errors (stochastic defects) that cannot be eliminated.65

High-NA EUV is the next evolution, but it only escalates the cost (Rock’s Law) and complexity.14



The “Bottom-Up” Ideal: STM Lithography



The conceptual opposite of EUV is STM Lithography, as described in Part 2.37 This “bottom-up” technique provides perfect, deterministic, atomic precision.37 Its throughput, however, is measured in atoms per second, making it commercially non-viable for manufacturing the billions of transistors on a VLSI chip. Its role is confined to R&D, quantum device prototyping, and fabricating “master templates.”



The Scalable Hybrid Model: DSA and ALD



The bridge between the low-precision/high-throughput of EUV and the high-precision/low-throughput of STM is a hybrid approach using scalable, bottom-up techniques:

  1. Atomic Layer Deposition (ALD): A process used to deposit materials one atomic layer at a time.67 It is a self-limiting chemical process, providing perfect uniformity and angstrom-level control over thickness. It is already used for high-k gate dielectrics 67 and is essential for growing 2D materials and barriers.68
  2. Directed Self-Assembly (DSA): A process where block copolymers (BCPs) are “painted” onto a wafer and self-assemble into highly ordered, sub-10 nm patterns (e.g., lines or dots).69 This self-assembly is “directed” by a simple, low-resolution “guide pattern” made with EUV, which the BCPs then “fill in” at a much higher resolution.69



The Future Paradigm: The “AI-Guided Fab”



The true future of manufacturing, as outlined in recent strategy papers, is a Multi-Modal Strategy that fuses all these techniques into a single, closed-loop system.71

This new fabrication paradigm works as follows:

  1. Seeding: A sparse “seed” pattern is created using either low-pass EUV or (in critical areas) high-precision STM/e-beam lithography.71
  2. Amplification: Scalable, bottom-up processes like DSA and ALD are used to amplify and grow the complex circuit from these seeds, using 2D materials or other scaffolds.71
  3. Real-Time Correction (The AI Loop): This is the revolutionary step. An in-situ metrology tool (like a Helium Ion Microscope) scans the wafer during the fabrication process. An AI model, acting as an “AI co-fabricator,” compares the atomic-scale growth against the “digital twin” (the chip design) in real-time. This AI then autonomously directs ion or electron beams to trim features, repair defects, or correct placement errors on the fly.71

This AI-guided, multi-modal “fab-in-the-loop” is the only plausible path to bridge the gap between single-atom lab curiosities 36 and angstrom-scale VLSI, finally moving manufacturing from a probabilistic, top-down art to a deterministic, bottom-up science.

Table 2: Disambiguation of “Quantum” Terminology in Semiconductor Devices



Term Core Concept Primary Function Operational Domain End Goal
Quantum-Effect Transistor (e.G., TFET) Quantum Tunneling (BTBT) 3 Ultra-low-power classical logic (0/1 switch) Room Temperature A “better switch” (to beat 60mV/dec) 4
Single-Atom Transistor Coulomb Blockade / Quantum Levels 36 N/A (Research); Proof of atomic fabrication 37 Cryogenic 36 R&D: The ultimate scaling limit
Transistor-as-Qubit (Silicon Spin Qubit) Quantum Dot (trapping a single electron) 72 Hosting a quantum state (Superposition/Spin) 73 Millikelvin (mK) 74 A “new computer” (probabilistic) 7
Qubit Readout Sensor (SET) Coulomb Blockade 34 Sensing the qubit state (Spin-to-charge conversion) 10 Millikelvin (mK) 35 A “quantum sensor” for the QPU

Part 4: Fabricating True Quantum Computers: The Silicon Qubit Approach



This section now moves to “Path 2”: the use of semiconductor fabrication to build true quantum computers. Here, the “transistor” takes on a new, non-classical role.



Clarification: Classical vs. Quantum Architecture (The Qubit)



First, it is essential to define the profound computational difference.

  • A classical bit, whether in a MOSFET or a TFET, is a deterministic switch, existing in a state of “0” or “1”.75
  • A qubit (quantum bit) is a quantum-mechanical system that leverages superposition. A qubit can exist in a linear combination of both states—”0″ and “1”—simultaneously.6

When multiple qubits are entangled, their states remain linked regardless of distance.75 This allows a quantum computer to explore a massive computational space in parallel. While a classical computer’s power scales linearly with the number of transistors, a quantum computer’s power scales exponentially with the number of qubits.78

A quantum computer is not a general-purpose replacement for a classical CPU. It is a specialized accelerator, or Quantum Processing Unit (QPU), designed to solve specific classes of problems that are intractable for classical computers, such as quantum simulation, complex optimization, and cryptography.77

Critically, the architecture of the QPU (the physical layout and connectivity of the qubits) and the quantum algorithm are deeply intertwined and must be “co-designed” for a given problem.80 This implies the future of high-performance computing is a hybrid model: a classical HPC (likely built with the CNFETs or TFETs from Part 2) connected to a specialized QPU co-processor.



Silicon Spin Qubits: The Scalable Path



While many technologies exist for building qubits (e.g., superconducting circuits, trapped ions), industry leaders like Intel 9 and IBM 8 are investing heavily in silicon spin qubits. This is the second meaning of the “quantum transistor.”



The “Transistor-as-Qubit”



In this architecture, a “transistor”—often a FinFET 72 or a “gate-defined quantum dot” 73—is not used as a switch. Instead, it is used as a nanoscale “electrostatic cage” to trap a single charge carrier (an electron or a “hole”).72

The qubit is the spin of this trapped particle—a natural two-level quantum system (spin “up” = $|1\rangle$, spin “down” = $|0\rangle$).9 The “transistor” gates are then used to apply microwave pulses to control this spin state 73 or manage the “exchange interaction” between two adjacent qubits to perform a 2-qubit logic gate.82



The Economic Advantage: Leveraging the CMOS Fab



The “killer app” for silicon spin qubits is not their physics (though their coherence times are excellent 9)—it is their manufacturability.

Silicon spin qubits are “process compatible with CMOS”.9 This is a profound economic advantage. Building a fault-tolerant quantum computer will require millions of physical qubits.9 IBM is already fabricating its quantum chips at the Albany NanoTech Complex on 300mm semiconductor wafers, using the same “state-of-the-art” tools as classical chips.8 Intel is using its advanced transistor fabrication processes for the same purpose.9

This is the only known path to fabricating millions of qubits. It leverages the multi-trillion-dollar R&D and capital investment in the global CMOS manufacturing ecosystem. It effectively solves the “Rock’s Law” economic barrier (from Part 1) for quantum computing.



The Quantum-Classical Interface: Cryo-CMOS and Readout



A quantum processor with millions of silicon spin qubits operating at millikelvin (mK) temperatures 74 creates a new, massive “I/O bottleneck.” It is physically impossible to run millions of control wires from the room-temperature classical computer down into the cryogenic refrigerator.



Solution: Cryo-CMOS



The only viable solution is to build a classical control chip that can operate at cryogenic temperatures, sitting right next to the QPU.74 This Cryo-CMOS controller (itself built with billions of low-power transistors) handles all the low-level, real-time tasks: multiplexed qubit addressing, digital-to-analog conversion, pulse generation, and readout.85 This dramatically reduces the number of wires that need to leave the cryostat.



The “SET-as-Sensor” (Revisited)



This Cryo-CMOS chip must be able to read the final state of the qubits. A qubit’s spin state, however, is notoriously difficult to measure. The system employs spin-to-charge conversion.10 The spin state (up/down) of the qubit is correlated with the charge position of a single electron.

This single-electron movement is an imperceptible electrical event… except to a Single-Electron Transistor (SET).

This is the critical convergence of “Path 1” and “Path 2.” The SET, which was a poor candidate for logic (Part 2), is fabricated directly next to the silicon spin qubit.35 Its extreme electrostatic sensitivity makes it the perfect sensor to detect this single-charge movement and convert the quantum spin state into a classical voltage signal (“0” or “1”) that the Cryo-CMOS controller can read.10

This leads to the final, converged vision: the “Quantum System-on-a-Chip (SoC).” The ultimate “quantum chip” is a monolithic, 3D-integrated, hybrid device.

  1. The Qubit Layer: A 2D array of silicon spin qubits (repurposed transistors).72
  2. The Sensor Layer: An array of Single-Electron Transistors (SETs) integrated for qubit readout.35
  3. The Control Layer: A massive Cryo-CMOS classical processor (likely built with billions of low-power TFETs or CNFETs) for multiplexed control, error correction, and data processing.74

This “Quantum SoC” is the ultimate expression of the heterogeneous integration strategy and the convergence of both “quantum” semiconductor paths.



Part 5: Architectural Futures and Commercial Landscape



The advent of these new quantum-effect devices (TFETs, CNFETs, SETs) and 2D materials (TMDs) does not just enable smaller, faster chips. It unlocks entirely new computer architectures that were previously impossible.



New Architectures for Classical Computing



Pragmatic (Hybrid-Core): The “HetCore” Architecture



A near-term, pragmatic approach to integrating new devices is the “HetCore” (Hetero-device Core) architecture.88 This is a standard CPU or GPU core that selectively replaces high-power, non-latency-critical units (like L1 data caches) with slower but hyper-efficient TFETs.88 The high-speed critical path (e.g., the ALU) remains in fast, high-power CMOS.

In this model, the TFET units (running at a lower $V_{DD}$) are more heavily pipelined to run at the same clock frequency as the CMOS units.88 This hybrid approach offers the best of both worlds, achieving average energy savings of ~40% with a minimal performance degradation of only 10-20%.88 This provides a realistic, evolutionary path for foundries to begin integrating new devices without a complete architectural revolution.



Radical (Non-Von Neumann): In-Memory and Neuromorphic Computing



The more profound impact of these new devices is the ability to break from the 70-year-old von Neumann architecture.43 The “von Neumann bottleneck” is the physical separation of the Central Processing Unit (CPU) and the memory (DRAM/NAND), and the massive amount of energy (up to 90% of a system’s total) wasted simply shuttling data back and forth between them.90

  1. In-Memory Computing (IMC): New devices, particularly those based on 2D materials, can be both a memory cell and a logic gate simultaneously. For example, a dual-gate anti-ambipolar transistor (AAT) using a $\text{ReS}_2/\text{WSe}_2$ heterojunction and a $\text{ZnPc-PS}_4$ memory layer is electrically reconfigurable.92 By changing a control voltage, it can function as an AND, OR, NAND, NOR, or XOR gate, while also storing the result non-volatilely.92 This enables Processing-in-Memory (PIM) 93, where computation happens inside the memory array, eliminating the von Neumann bottleneck.
  2. Neuromorphic Computing: This is a brain-inspired architecture that seeks to emulate the structure of biological neurons and synapses.95 These systems, such as Spiking Neural Networks (SNNs) 93, require devices that are analog, multi-state, and can “spike”—a perfect match for the multi-level quantum-well devices (like the single-atom transistor 36) and memristive/phase-change devices (like FeFETs and ReRAM) discussed earlier.89 These brain-inspired systems can be over 1,000,000 times more energy-efficient than modern computers for AI and pattern-recognition tasks.44 This non-von Neumann approach is conceptually similar to analog quantum computing (like quantum annealing), as both use the “physics” of the system to naturally “settle” into a low-energy state that represents the solution to a complex problem.7



The Commercialization Ecosystem: Leaders and Challengers



The “beyond silicon” landscape is a high-stakes race between established incumbents (evolution) and disruptive startups (revolution).

  • R&D Incumbents (The “Evolution” Strategy): The industry giants are leveraging their massive R&D budgets and fabs to pursue a heterogeneous integration model.
  • Intel: Driving research into Gate-All-Around (GAA) silicon transistors, 2D-material FETs, and is a leader in silicon spin qubit fabrication.9
  • TSMC: Collaborating heavily with academia (MIT, UC Berkeley) to develop 2D materials (MoS$_2$) and CNFETs as 3D-stackable “beyond silicon” technologies to be built on top of their logic.16
  • IBM: Leveraging its 300mm quantum chip fabrication line 8 and its long legacy in CNT research.104
  • imec: The world’s leading independent nanoelectronics R&D hub in Belgium. Imec partners with all major players (Intel, TSMC, Samsung) to de-risk next-generation technologies like 2D-TMDs and advanced patterning, setting the pre-competitive industry roadmap.105
  • Academic Foundries: The breakthroughs that enable this transition are overwhelmingly born from university labs, often funded by government agencies like DARPA and the NSF.55 MIT (CNFET RISC-V processor, 2D-TMD integration) 5, Stanford (CNFET logic, 2D materials) 46, and UC Berkeley (BSIM modeling, 2D-TMD transistors) 100 have created the foundational IP for this new era.
  • The Emerging Startups (The “Revolution” Strategy): A new ecosystem is forming to challenge the incumbents by building a new, non-silicon supply chain from scratch.
  • Graphene/2D Foundries: Pure-play 2D-material foundries and device makers have emerged, such as Paragraf (which markets “Graphene electronic devices. Industry ready. Now.”) 59, Graphenea 112, Black Semiconductor (which acquired a graphene specialist to accelerate its photonic chip timeline) 113, and Destination 2D.114
  • CNFETs: The mature MIT/Stanford research 47 has been proven scalable in commercial fabs (e.g., SkyWater Technology 52) and is now prime for high-volume commercialization, either by a dedicated startup or acquisition by an incumbent.
  • Quantum: While Intel and IBM focus on silicon qubits, startups like PsiQuantum are pursuing revolutionary, non-transistor-based paths, such as photonic quantum computing.115

This defines the central strategic battle: the incumbents’ evolutionary model (leveraging billion-dollar fabs for 3D-heterogeneous integration) versus the startups’ revolutionary model (building a new, dedicated, non-silicon supply chain).

Table 3: The Atomic-Scale Manufacturing Roadmap



Manufacturing Strategy Key Process Resolution Limit Throughput Primary Application
“Top-Down” (Current) EUV / High-NA EUV Lithography 63 $\approx$ 1-10 nm (Stochastic limit) 65 High (Wafers/hour) High-Volume VLSI (Silicon FinFETs)
“Bottom-Up” (Precision) STM Lithography 37 < 1 nm (Atomic precision) 37 Extremely Low (Atoms/sec) R&D, Prototyping, Qubit Fabrication
“Hybrid / Scalable” (Future) Directed Self-Assembly (DSA) 69 $\approx$ 3-10 nm High (Self-assembling) Scalable patterning, cost-reduction
“Hybrid / Scalable” (Future) Atomic Layer Deposition (ALD) 67 $\approx$ 0.1 nm (Single layer) High (Self-limiting) Gate oxides, 2D material growth
“Future Paradigm” AI-Guided Multi-Modal Fab 71 Angstrom-scale 71 High (Closed-loop) Deterministic, defect-free, hybrid-material (CNFET/TMD/Si) VLSI 71

Strategic Forecast and Recommendations



This analysis of the post-silicon landscape, from quantum-effect devices to true quantum processors, leads to the following 10-year strategic forecast and recommendations.

  1. CNFETs are the highest TRL (Technology Readiness Level) for a silicon logic replacement. The demonstration of a 14,000-transistor RISC-V processor in a commercial fab (the RV16X-NANO) 5 has de-risked the primary manufacturing hurdles. The most likely near-term application (5-7 years) will be as a 3D-stacked “monolithic” layer for on-chip cache (SRAM) or memory, followed by integration into high-performance logic blocks.
  2. TFETs (specifically NC-TFETs and 2D-TMD TFETs) are the most promising low-power replacement. The combination of negative capacitance (for a 10 mV/dec “hack”) 22 and 2D materials (for ideal electrostatics) 25 provides a clear path to overcoming the Boltzmann tyranny. Adoption will be slower than CNFETs, as it hinges on mastering the manufacturing of its complex, multi-material (ferroelectric + 2D-TMD) stack.
  3. Silicon Spin Qubits are the only economically viable path to a fault-tolerant quantum computer. The ability to leverage the existing 300mm CMOS-fab infrastructure 8 is a decisive, multi-trillion-dollar advantage over all other qubit modalities. The primary challenge is not fabrication; it is solving the fundamental physics problems of qubit coherence, control, and error correction at scale.6

Final Recommendation:

The central ambiguity of the term “quantum transistor” is, in fact, the key to the future. It is not one device or the other. The two paths will converge.

The primary strategic risk for any semiconductor firm, investor, or nation is not betting on the wrong device. The risk is failing to invest in the hybrid manufacturing and architectural-design capabilities required to integrate them.

The winners of the next computational era will not be those who build a “pure” CNFET chip or a “pure” TFET chip. The winners will be those who master the heterogeneous, 3D-monolithic integration required to build a single, cohesive system that fuses:

  • A silicon foundation.
  • CNFETs for high-speed logic.
  • TFETs for low-power logic and Cryo-CMOS.
  • 2D-TMDs for TFET channels and memristors.
  • SETs as sensors.
  • Silicon Spin Qubits as a co-processor.

The future of chip design is the hybrid “Heterogeneous Core” (Part 5) 88 and the “Quantum SoC” (Part 4).84 Success will be defined not by the switch, but by the system.
